Silicone Coated Fiberglass Tape

QIAN-ZE Silicone Coated Fiberglass Tape provides the same protection against extreme heat conditions and occasional direct flames as QIAN-ZE Fire sleeve but in a versatile way. It is specially designed to protect components of irregular shape or varying dimension tapered pipes. Typically, the fiberglass high temp tape is overlapped by 30%, which provides the entire assembly with enhanced protection performance.


QIAN-ZE Silicone Coated Fiberglass Tape is braided from incombustible E-grade fiberglass and covered with a thick layer of silicone rubber that is highly resistant to hydraulic fluids, lubricating oils, and fuels. The kind of silicone coated tape provides excellent thermal insulating performance with the additional benefit of protecting the underlying heat resistant fiberglass tape from oils and other contaminants, as well as molten metal splash. QIAN-ZE, one of the professional thermal insulation suppliers, offers top-quality silicone rope for sale. Contact us now to get more info about heat resistant silicone tape!


Silicone Coated Fiberglass Tape Get a Quote
  • Silicone Coated Fiberglass Tape
  • Silicone Fiberglass Tape
  • Silicone Coated Tape
  • Silicone Coated Fiberglass Tape
  • Silicone Fiberglass Tape
  • Silicone Coated Tape
  • Silicone Coated Fiberglass Tape
  • Silicone Fiberglass Tape
  • Silicone Coated Tape
  • Silicone Coated Fiberglass Tape
  • Silicone Fiberglass Tape
  • Silicone Coated Tape

What Is Silicone Coated Fiberglass Tape Used For?

Silicone coated fiberglass tape is composed of twisted glass fiber strands. These threads are woven at right angles to form a glass fiber cloth of a specific width. In order to prevent the cloth from being untied continuously, it includes the edges of leftover materials. The composition of fiberglass fire sleeve makes it have impressive water resistance.

Silicone coated fiberglass tape is widely used to glue dry walls, the junction between door and window frames and walls, plaster to repair cracked gypsum and seal cracks in walls to prevent the formation of cracks.

Why Is Fireproof Silicone So Heat Resistant?

Fiberglass high temp tape has low thermal conductivity. This means that it transfers heat much more slowly than some other materials, so it has excellent heat resistance. Heat resistant fiberglass tape can also be described as having good "thermal stability", which means that it can maintain its structure and characteristics over a wide temperature range.

The heat tolenrance of heat resistant silicone tape is mainly due to the highly stable chemical structure of the material. The skeleton of siloxane is a stable structure, which does not allow the material to degrade when heated. With such excellent characteristics, it is no wonder that thermal barrier materials has such a wide range of applications and uses.


Quick Reference of Silicone Coated Fiberglass Tape

Materials

E-grade Fiberglass & Silicone Rubber Coating

Recommended Operating Temperature

Continuous: 260℃(500℉) (Silicone Rubber)

650℃(1200℉)(E-grade Fiberglass)

Instantaneous: 1650℃(3000℉)

Size Range

Width:25mm-165mm(1”-6.5”) (Other size can also be customized)

Color

Red (Other colors can also be customized)

Typical Industries

Transportation (Aerospace, Auto, Locomotive, Heavy Equipment)

Metals, Iron & Steel

Hose Fabrication

Oil & Gas

Robot Automation

Application

Hose and Cable Heat & Flame Protection

Water/Oil Proof

Acid Resistant

Anti-aging

Silicone Coated Fiberglass Tape Specification

Silicone Coated Fiberglass Tape

XM Part No.

Width

Wall Thickness

Roll Length

mm

inch

mm

inch

m/r

XM-FT-25

25

1

3

1/8

25

XM-FT-35

35

1.4

3

1/8

25

XM-FT-45

45

1.8

3

1/8

25

XM-FT-50

50

2

3

1/8

25

XM-FT-60

60

2.4

3

1/8

25

XM-FT-65

65

2.6

3

1/8

25

XM-FT-70

70

2.8

3

1/8

25

XM-FT-90

90

3.5

3

1/8

25

XM-FT-100

100

4

3

1/8

25

XM-FT-120

120

4.7

3

1/8

25

XM-FT-150

150

6

3

1/8

25

XM-FT-165

165

6.5

3

1/8

25

Silicone Coated Fiberglass Tape
